Page #116 background image
116
CS175-275-575-875 Installation Guide
Seg 3
Call back windows timer (Default = 5 minutes)
Determines the amount of time, in one-minute increments, the CS534 waits
for a call back when enabled in location 0, segment 1 or initiated by the
central station. Possible increments are 1 to 255 minutes. See
Control levels
on page 112 for more information.
Seg 4
Wrong PIN digit entries (Default = 12)
Determines the maximum number of digits that can be entered for call back
and call-in features (location 0, segments 1 and 6). Valid entries are 6 to
255. (Default = 12)
Seg 5
Session inactivity hang-up time (Default = 90 seconds)
Determines how long the CS534 remains on the phone line with no activity
from the central station. This time can be programmed from 30 to 255
seconds.
Seg 6
Time remaining tone indicator-A (Default = 20 seconds)
Determines how many seconds remain when the CS534 sends tone
indicator “A” to the central station. This time is used to alert the central
station that the two-way session is terminated if there is no further activity
from the central station. Valid entries are 1 to 255 seconds.
Seg 7
Time remaining tone indicator-B (Default = 10 seconds)
Determines how many seconds remain when the CS534 sends tone
indicator-B to the central station. This time is used to alert the central station
that the two-way session is terminated if there is no further activity from the
central station. Valid entries are 1 to 255 seconds.
Seg 8
Anit-lock-up tone time (Default = 0 seconds)
Determines at what interval the anti-lock-up tone is heard at the central
station. This tone is used to prevent noise in an exceptionally loud
environment from interfering with central station’s control of the two-way
session. The possible values are 0 to 255 seconds. If a zero “0” is
programmed (default), it is disabled and no tone is generated.
Location 4 Volume/ring control (four segments, ND)
Segment 1
Low gain listen-in mode microphone volume (Default = 5)
Controls the volume of the microphones when low-gain listen-in
mode is selected by the central station. The possible values for this
location are 0 to 9 (maximum volume is 9 and minimum is 0).
Segment 2
High gain listen-in mode microphone volume (Default = 9)
Controls the volume of the microphones when high-gain listen-in
mode is selected by the central station. The possible values are 0
to 9 (maximum volume is 9, minimum volume is 0).
Segment 3
Speaker volume (Default = 9)
Governs the volume of the speaker when talk is selected by the
central station. The possible values for location 4 are 0 to 9
(maximum volume is 9, minimum volume is 0).
Segment 4
Number of rings to answer for call-in feature (Default = 0)
Determines the number of rings the CS534 must see before
answering the call while in call-in mode (location 0, segment 6).
Valid entries are 0 to 9. If a zero “0” is programmed, it is disabled. A
master code is required within 20 seconds of the line pickup or the
line is disconnected.
