Guidance and manufacturer’s declaration – electromagnetic immunity
Immunity test
IEC 60601-1-2
test level
Compliance level
Electromagnetic environment -
guidance
Power
frequency
Magnetic field
EN 61000-4-8
30A/m
50 Hz or 60 Hz
30A/m
50 Hz
Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
±0,5kV ±1kV;
±2 kV, AC
Mains, Line to
Ground
±0,5kV ±1kV,
AC Mains,
Line to Line
±0,5kV ±1kV; ±2
kV, AC Mains, Line
to Ground
±0,5kV ±1kV, AC
Mains, Line to Line
Voltage dips,
short
interruptions
and
voltage
variations
on power supply
input lines
IEC 61000-4-11
0 % UT; 0,5
cycle
At 0°, 45°, 90°,
135°, 180°,
225°, 270° and
315°
0 % UT; 1
cycle
and
70 % UT;
25/30 cycles
Single phase:
at 0°
0 % UT;
250/300 cycle
0 % UT; 0,5 cycle
At 0°, 45°, 90°,
135°, 180°, 225°,
270° and 315°
0 % UT; 1 cycle
and
70 % UT; 25/30
cycles
Single phase: at 0°
0 % UT; 250/300
cycle
NOTE: U
T
is the AC mains voltage prior to application of the test level.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the product is used
exceeds the applicable RF compliance level above, the product should be observed to
verify normal operation. If abnormal performance is observed, additional measures may be
necessary.
b
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 1 V/m.
