*XT = function available on ALEXA XT/XR only *ANAMORPH = requires Anamorphic Desqueeze License *DNxHD = requires DNxHD License *HS = requires
High Speed License *PLUS = ALEXA PLUS only *PLUS 4:3 = ALEXA PLUS 4:3 only *STUDIO = ALEXA STUDIO only *M = ALEXA M only *NON XT = only
available on ALEXA „Classic“ cameras *OG = settings and values introduced by the Open Gate Mode are not covered by this overview.
SUP 9.0
HOME
BACK & JOGWHEEL
press BACK while turning the jogwheel
to change the display brightness
continued on next page
Quick-option for choosing
REC and MON fps
Change volume of channel
1 and 2 with jogwheel
Limited to 11.2°-180.0° on
ALEXA (XT) STUDIO with
enabled mirror shutter
Enable mirror shutter on
ALEXA (XT) Studio
AUDIO
adjust
CH1+/- (level +20/-10; unity)
adjust CH2+/- (level +20/-10; unity)
AUDIO OUT
set AUDIO OUT
Phones Level (+/-)
OPTIONS
AUDIO OUT > OPTIONS >>
Left out (CH1, CH2, CH1+2, None)
Right out (CH1, CH2, CH1+2, None)
Audio OUT level (Manual, Unity max.)
OPTIONS
AUDIO IN > OPTIONS >>
Record (On/Off)
Channel 1/2 level (Manual/Unity)
Channel 1/2 source (L/R in)
Soundroll (=Tape) (edit name)
SHUTTER
set shutter angle (5.0°-358.0°; 172,8°)
in highspeed mode (5.0°-356.0°)*
ALEXA XT/S
add/delete value
see calculated exposure time
MIRROR*
ALEXA XT STUDIO/STUDIO
(On/Off)
EI
set exposure index (160ASA-3200ASA; 800ASA)
ND FILTER*
ALEXA XT STUDIO/STUDIO
(On/Off)
FPS
set sensor speed (0.75 fps-60fps /120fps*
ALEXA XT/HS
; 24fps)
add/delete value
HIGHSPEED/EXIT HS
*ALEXA XT/HS
(boot ALEXA to HS mode; 60-120fps)
MODE (MENU > RECORDING > INTERNAL)
MEDIA INFO (INFO > MEDIA INFO)
SDI FPS >>
REC OUT (23.976, 24, 25, 29.97 or 30fps)
MON OUT (23.976, 24, 25, 29.97 or 30fps)
