ARRI SkyPanel User Manual

Protocol
51
Mode 4: RGBW, 8 bit Resolution per Function Mode 5: HSI, 8 bit Resolution per Function
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
0-255 0-100
Intensity red
0% → 100%
3
0-255 0-100
Intensity green
0% → 100%
4
0-255 0-100
Intensity blue
0% → 100%
5
0-255 0-100
Intensity white
0% → 100%
6
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
7-9 Reserved (only V4.x)
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
0-255 0-100
Hue
0° → 360°
3
0-255 0-100
Saturation
0 → full saturated
4
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
5-7 Reserved (only V4.x)

ARRI SkyPanel Specifications

General

Type	LED Soft Light
Color Temperature	2800K - 10000K
CRI	≥ 95
Dimming	0 - 100%
Control	DMX, Ethernet
Input Voltage	100-240V AC, 50/60Hz
