Operational Procedures
When the units have been assembled.
eSTOP™ Lantern Unit
1. Connect power cable from eSTOP™ unit to battery box. To switch on the eSTOP™ unit, push the
small green Power Switch underneath the lantern unit (flip guard installed. So, flip it open to
operate the switch). The green LED light will illuminate when powered on. The lantern unit will be
controlled its master - the Handheld Remote Controller (HRC) once the HRC is paired.
Modes - The unit runs in two modes, the ‘Test Mode’ and ‘Operation Mode’.
Test Mode – when the unit first powers on, by default is in test mode. In this mode the
HRC can be used to perform lantern test. See HRC procedures for LED test function, each
lantern will light on for 0.5 seconds.
Operation Mode – The unit can be activated (using HRC) to ‘operation mode’ after power-
on/LED test. See HRC procedures for operation functions, when the unit first activates it
will flash Yellow for 5 seconds then default to Red, then halts for 5 seconds before it can
be operated.
Note: The eSTOP cannot be changed from Test mode to operation mode without
performing the LED test procedure.
2. When the lantern unit is on the RED state, a small yellow LED, called the “Red Light Indicator” will
flash. This Red-Light Indicator shall be facing the workers on the worksite. Its purpose is to indicate
to the workers on the jobsite that the traffic lantern is on red. The Red-Light Indicator shall NOT
face the motorists.
3. The eSTOP™ Lantern Unit is also fitted with a “Cut-Off Switch”. This is the Power Switch, located
at the base of the lantern. This switch will turn off the lantern instantaneously as required. Must
also be switched of when not in use.
Note: When setting up the eSTOP™, the lanterns shall face away from motorists during test mode, then once tested
and ready for operation, face the lantern towards traffic. Ensure to start activating the lights after the lantern is facing
the traffic, and not to turn the lantern face again.
