eSTOP™ Operations & Service Manual
Arrow Emergency Systems | 17 Bailey Court Brendale Q 4500 | P: (07) 3881 3302 | www.arrowes.com.au
Page |
4
eSTOP™ System Components Diagram
eSTOP™ Lantern Unit
Red light indicator
Lantern
Power switch
Battery supply power cable
Removable battery pack
Battery secure latch (both sides)
Battery pack holder
Locking screw
Centre column
Adjustable locking column
Locking pin
Legs
Figure 1
