Arthrex Synergy UHD4 Series User Manual

950-0073-00 B SM, English, Arthrex Synergy UHD4 System 18 of 74
Figure 5- AR-3210-0018 HD, SynergyUHD4 Camera Head, autoclavable
1.9.3 Camera Heads with Integrated Optics
1. Button 1 A programmable button that
can activate various functions of the
camera. See “Optional Tablet Data Input
Device” for programming information.
2. Button 2 A programmable button that
can activate various functions of the
camera. See “Optional Tablet Data Input
Device” for programming information.
3. Focus Ring Used to sharpen, or bring
into focus, the image detail.
4. Grasping Mechanism Accepts and
locks into place the compatible scope.
DIN 58105 compliant endoscope
interface.

Arthrex Synergy UHD4 Series Specifications

General

Brand	Arthrex
Model	Synergy UHD4 Series
Category	Camera Accessories
Language	English
