Arthrex Synergy UHD4 Series User Manual

950-0073-00 B SM, English, Arthrex Synergy UHD4 System 54 of 74
4.4 Troubleshooting
Symptom
Possible Cause
Corrective Action
Camera does not
power up. Standby
LED does not
illuminate.
 Power cord is unplugged.
 Suspect power cord.
 Plug power cord into CCU and/or a
properly grounded receptacle.
 Replace power cord.
Intermittent picture.
 Verify camera head connector
card edge is fully inserted into
the CCU camera receptacle.
 Suspect video and/or power
cables.
 Suspect camera head or cable.
 Reinsert camera head connector card
edge.
 Flex video and power cables. If picture
is affected, inspect cables and replace
as necessary.
 Flex camera cable. If picture is
affected, return to factory for repair or
replacement.
Camera will not white
balance.
 Too much light.
 Too little light.
 Wrong Color Temperature
light.
 If monitor indicates “White Balance
Fail”, move the scope further away
from the white gauze when you white
balance, or turn down the light source
brightness.
 If monitor indicates “White Balance
Fail”, move the scope closer to the
white gauze when you white balance,
or turn up the light source brightness.
Camera head buttons
do not function as
programmed.
 Incorrect camera head button
programming.
 Reprogram camera head buttons.
NOTE: Tablet Data Input device option
only.
