Arthrex Synergy UHD4 Series User Manual

950-0073-00 B SM, English, Arthrex Synergy UHD4 System 55 of 74
Symptom
Possible Cause
Corrective Action
No video image on monitor.
 CCU and/or monitor are not
ON and/or plugged in.
 Equipment is not connected
properly or cable(s) damaged.
 Suspect camera head and/or
cable.
 Camera head cable connector
not inserted correctly or
completely.
 Plug CCU and/or monitor in
and/or turn power ON.
 Confirm cable connections
and reroute video cables, if
necessary per interconnect
diagram. Check video cables
for damage, replace as
necessary.
 Replace the camera head
with a working unit and verify
image on monitor. If image is
now viewed, the original
camera head and/or cable
were faulty, return them to
Arthrex for repair.
 Insert camera head cable
connector completely into the
console’s camera head
receptacle on the front panel.
 Check monitor using color
bars from the CCU.
 Try the CCU on a different
monitor.
Poor color reproduction.
 White Balance Issues.
 White Balance camera head.
 Check monitor settings using
color bars from the CCU.
 Try the CCU on a different
monitor.
System does not boot up
correction./Banners do not
display or do not display
properly.
 Improper shut down of CCU.
 Power down device, wait 3
minutes, and restart system.
