Arthrex Synergy UHD4 Series User Manual

950-0073-00 B SM, English, Arthrex Synergy UHD4 System 62 of 74
Safety, Classifications
Classification of Equipment
Parameter Value
According to protection against electric shock.
Class I [Grounded]
According to degree of protection against
electric shock.
Applied part is Type CF Defibrillation Proof
According to Degree of protection against
harmful ingress of water.
Camera Control Units are Ordinary [IPX-0] no
protection.
Camera Head is IXP-7 [Protected against
temporary immersion in water]
According to the degree of safety in the
presence of Flammable Anesthetics
Equipment is NOT suitable for use in the
presence of flammable anesthetics.
According to the mode of operation.
Continuous
Specifications
Parameter
Parameter Value
Power Requirements
Rated Voltage: 100 – 240 V~
Supply Frequency: 50-60 Hz
Power Input: 160 VA
Fuses: No user serviceable fuses
Video Outputs
Video Output
Description
Display Port (2x)
3480 x 2160 pixels [4K/UHD], 10-bit color
DVI (2x)
1920 x 1080 pixels [1080p], 8-bit color
3G-SDI (4x)
1920 x 1080 pixels [1080p], 8-bit color
Matrix Video (2x)
3480 x 2160 pixels [4K/UHD], 8-bit color (AR-
3200-0020 [CCU, Synergy UHD4, Matrix]
only)
Vertical Scanning
Frequency
59.94 Hz
Signal to Noise Ratio
> 52 -dB [4K]
> 48 -dB [HD]
White Balance Range;
Integrated Optics Head
2,500 – 9,000 K [4K]
2,000 – 9,000 K [HD]
White Balance Range
:C-Mount Head
3053 to 10,000 K
CCU Dimensions
Approximately: 17” [W] x 3.5” [H] x 13.5” [D]
43.2 cm [W] x 8.9 cm [H] x 34.3 cm [D]
CCU Weight
Approximately: 15 pounds/6.8 kg
