950-0073-00 B SM, English, Arthrex Synergy UHD4 System 69 of 74
IEC 60601-1-2
Guidance and manufacturer’s declaration electromagnetic immunity
The Arthrex
UHD4
Video System is intended for use in the electromagnetic environment specified below. The customer or user of the
Arthrex
UHD4
Video System should assure that it is used in such an environment.
Immunity Test
IEC 60601 test level
Compliance Level
Electromagnetic environment - guidance
Electrostatic discharge [ESD]
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or ceramic tile. If
floors are covered by synthetic material the relative
humidity should be at least 30%.
Electrical fast transient / burst
IEC 61000-4-4
± 2 kV differential mode
± 1 kV for input / output
lines
± 2 kV differential mode
± 1 kV for input / output
lines
Mains power should be that of a typical commercial
or hospital environment.
Surge
IEC 61000-4-5
± 1 kV differential
mode.
± 2 kV common mode.
± 1 kV differential
mode.
± 2 kV common mode.
Mains power should be that of a typical commercial
or hospital environment.
Voltage dips, short interruptions
and voltage variations on power
supply input lines
IEC 61000-4-11
< 5% U
T
[> 95% dip in U
T
] for
0.5 cycle.
40% U
T
[60% dip in U
T
] for 5
cycles.
70% U
T
[30% dip in U
T
] for 25
cycles.
< 5% U
T
[> 95% dip in U
T
] for 5
seconds.
< 5% U
T
[> 95% dip in U
T
] for
0.5 cycle.
40% U
T
[60% dip in U
T
] for 5
cycles.
70% U
T
[30% dip in U
T
] for 25
cycles.
< 5% U
T
[> 95% dip in U
T
] for 5
seconds.
Mains power should be that of a typical commercial
or hospital environment. If the user of the
Arthrex
UHD4
Video System requires continued
operation during power mains interruptions, it is
recommended that the Arthrex
UHD4
Video System
be powered from an uninterruptible power supply.
Power Frequency [50/60 Hz]
magnetic field.
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.
NOTE: U
T
is the a.c. mains voltage prior to application of the test level.
