9 Cable connections
9.1 Overview
CAT5E/CAT6 Ethernet cable
CAT5E/CAT6 Ethernet cable
USER PC*
Ethernet switch*
Internet
UPS*
Power cord
110/230VAC
Power cord
Remote USER PC*
(if you want to control the
telescope remotely)
Telescope Rack
Telescope Cable
* not included
Figure 31 – wiring overview
