ASA Electronics AZ800 - Page 52

AZ800 user manual - hardware
Created by: MPuchner 07.2019
version: 9600021A
Original user manual
page 52 of 68
printed: 04.03.2020
To adjust the offset you need to raise or lower the mirror by evenly using the push and pull screws, shown in the
picture below.
Figure 47 - how to adjust the tertiary mirror offset
