10. Opening the platform without remote controls
The platform can be opened without the aid of remote control.
First of all, open the service hatch cover on the top, rear of the lift.
There are two possible operating options:
• Open the platform with the push buttons (emergency folding)
• Open the platform with direct external electrical supply to the platform motor (e.g. battery of cordless
screw driver).
If the batteries are empty, bring the loose black cable with white terminal block (connection cable) directly
into contact with platform motor fuse or to the positive pole of the external power source.
If the batteries are charged, use the OPEN or CLOSE push buttons to operate the platform.
(This will also function when the remote controls are defective).
If the remote controls are at fault, connect the emergency power supply via black cable, directly to the 7,5A
Fuse. If the batteries are completely discharged, the emergency power supply cable must be connected to the
positive pole of the external power supply and the negative pole should be brought into contact with the
frame of the lift unit.
If the lift has not been correctly positioned at a charging station, it will automatically switch itself off after a
maximum of 10 hours in order to prevent a deep discharge of the batteries.
• To RESTART the lift unit, press the RESET button.
! ATTENTION ! Only use this solution when there is no voltage in the batteries!
• The platform can ONLY BE OPENED!
• Opening the platform with an emergency power supply, deactivates the safety limit switches!
As soon as the platform is horizontal, remove all power connections, otherwise the platform motor could be
subjected to an electrical overload!
