Ascendor PLK8 - Recommended Spare Parts Set

Maintenance and Service Manual Version 2.14 Page 9
4.10 Recommended spare parts set
We recommend taking a set of spare parts with you at all service operations.
Part number
Quantity
Description
XT401187
1
Bowden cable
KT000700
1
Radio receiver board 433,075MHz
XT401195
1
Main circuit board
10401
1
Wireless handheld transmitter
XT401467
2
Holder charging point, extra long
XT401547
2
Cover charging point, extra long
XT401516
1
Brass charging point
KT000436
2
Brass screw M4x16 for charging point PLG7
KT000479
2
Brass screw M4x30 for charging point PLK8
XT401223
1
Platform motor
KT000081
1
Safety catcher
KT000061
4
Battery 12V 7,2Ah
KT000239
3
Fuse 30 A
KT000297
3
Fuse 40 A
KT000407
3
Fuse 7,5A
KT000016
3
Miniature switch with roller lever
KT000017
2
Miniature switch, positively driven NC contact
KT000037
1
Limit switch up/down FR 555 1M1
KT000090
3
Miniature switch for contact tray, outdoor unit
XT401338
10
Rubber buffer for contact tray
KT000446
2
Proximity switch curve-travel
XT501093
5
Distance for bracket PLK8 3mm
XT501094
5
Distance for bracket PLK8 5mm
XT501095
5
Distance for bracket PLK8 1,5mm
XT401766
5
Distance for bracket 3mm PLG7
XT401767
5
Distance for bracket 1,5mm PLG7
XT401774
5
Distance for bracket 5mm PLG7
KT000247
3
Plastic cap stanchion, tube 60x60mm
KT000622
3
Plastic cap stanchion, tube 80x60mm
KT000315
2
Plastic cap hexagon nut, wrench size 17
KT000316
2
Plastic cap hexagon nut, wrench size 19
XT401528
2
Cover charging point PLG7
KT000607
1
Charger Soneil
XT401529
4
Rail end cap 42,4x3,2mm stainless steel
KT000432
5
Hexagon bolt M10x30 stainless steel
KT000429
5
Hexagon socket bolt ISK M10x30 stainless steel
If you find a broken spare part during service you can order it with the part number by your distributor.
You find a list of all spare parts in the spare parts catalogue.
