INSTALLATION GUIDE
IP-DECT Base Station and IP-DECT Gateway
Installation of the Base Station
Back view while lying down
MCX connectors
7. Mount the base station (3), see 3.2.9 Mount the Base Station, page 22.
Figure 11. Connect external antennas.
TOP
Min 74 mm
Max 250 mm
1
3
coaxial cable
lock nut
antenna
base station
antenna bracket
mounting bracket
2
TOP
TD 92989EN / 25 January 2021 / Ver. E
20
