ASCOM IP-DECT Base Station Installation Guide

INSTALLATION GUIDE
IP-DECT Base Station and IP-DECT Gateway Description
• Two antennas
• A mounting bracket
• Two screws with wall plugs
The IPBS1 cannot be mounted with the antennas pointing downwards as the mounting bracket
does not support it.
Insert the antennas into the IPBS1 before following the installation instructions in 3.2 Install the Base Station,
page 16.
2.2 IPBS2/IPBS3
The following versions of the IPBS2 and IPBS3 are available:
• IPBS2 with internal antenna
• IPBS2 with external antennas
• IPBS3 with internal antenna
• IPBS3 with external antennas
The IPBS2/IPBS3 is backward compatible with the IPBS1 when it comes to coverage, functionality,
accessories and mounting bracket. If an old IPBS1 has to be replaced you just reuse the mounting bracket
and install the IPBS2/IPBS3.
TD 92989EN / 25 January 2021 / Ver. E
4
