ascon M3 Series User Manual

275..0
274.8
prot
baud
Ht.f.s
Code
rtH
retr
t.run
35
4 - Operations
4.6 CONFIGURATION
The configuration of the controller
is specified through a 4 digit code
that defines the type of input, of
control output and of the alarms.
(sect. 3.2 page 18)
Press
$ or % to display the
next parameter or the next code
and change its value.
The new value entered is stored into
the controller when the next para-
meter is selected by pressing
è.
Pressing the í the next group
of parameters is displayed.
Values
modification
Enter key for
selection and
value setting
confirmation
Configuration
menu access
200.2
Conf
Parameter
value
Parameter
mnemonic
Operator mode Timer run/stop
(if option installed)
Retransmitted signal
(only if OP4 is present)
p.U. / s.p.
CT primary high range
(only if installed)
10…200 A
Password [3]
0…9999
33 di default from factory
Communication protocol
(only if communication is
installed)
M.bu5 / jbus
Baude rate
(only if comm.is installed)
1200/2400
4800
/9600
Retransmission range
(only if present)
0=20 / 4=20 mA
