ascon M3 Series User Manual

5
1 - Installation
1.2 DIMENSIONAL DETAILS
48 mm
1.89 in
120 mm
4.72 in
48 mm
1.89 in
20 mm max
0.79 in max
1.3 PANEL CUT-OUT
65 mm min
2.56 in min
45
+0.6
mm
1.78
+0.023
in
45
+0.6
mm
1.78
+0.023
in
65 mm min
2.56 in min

ascon M3 Series Specifications

General

Brand	ascon
Model	M3 Series
Category	Temperature Controller
Language	English
