ascon M3 Series User Manual

28
4 - Operations
4.5 PARAMETERS
The controller parameters have
been organised in group, accord-
ing to their functionality area.
AL2 alarm
threshold
AL3 alarm
threshold
The alarm occurrences handle the
OP1, OP2 and OP3 outputs, in dif-
ferent ways, according to the con-
figured types of alarms, as illus-
trated.
With double action control out-
put, AL2 and AL3 share in or
mode the same output (the free
one) (see table on page 13)
#A3s.p
#A2s.p
FIRST GROUP
Absolute alarm (full scale)
On
Off
Active
high
Active
low
hy
high rangelow range
Alarm threshold
On
Off
Deviation alarm
On
Off
Active
high
Active
low
hy
+ high range- low range
Alarm threshold
On
Off
SP
T
Sensor break or input disconnection
over-range
under-range
VisualisationSensor
