2 - Electrical connections
2 ELECTRICAL
CONNECTIONS
UL note
[1] Use 60/70 °C copper (Cu) con-
ductor only.
2.1 TERMINATION UNIT [1]
B
18 screw terminals
Option terminals
Holding screw 0.5 Nm
Pin connector
q 1.4 mm
0.055 in max
Ø
Fork-shape
AMP 165004
Ø 5.5 mm - 0.21 in
Stripped wire
L 5.5 mm - 0.21 in
Terminals
L
0,5
Nm
6
5
4
3
2
1
12
11
10
9
8
7
16
15
18
17
14
13
Rear
terminal
cover
Cable size
1 mm
2
18 AWG
5.7 mm
0.22 in
Positive screw
driver PH1
Negative screw
driver 0,8 x 4 mm
6
5
4
3 9
2 8
1 7
12
11
10
18
17
16
15
14
13
18V
OUT
RTD
N
L
B
TA
OP3
NO
C
RS485
(OP4)
OP2-R
NO
C
NO
C
OP1
OP2-L
b
TC
mA
mV
A
