CPU 1021/A User’s Guide
2 Asem S.p.A.
Technical specifications
Processor
Intel
®
Core
®
2 Duo, Intel
®
Core
®
Duo,
Intel
®
U7x00, Intel
®
U2x00, Intel
®
Celeron
®
5x0, 4x0, Intel
®
Celeron
®
ULV
(Ultra Low Voltage) 5x3, 4x3
Chip-set
Intel
®
GME965 + ICH8M
RAM
Up to 4 GB (2GB x 2 So DIMM DDR2)
BIOS
FW HUB on LPC of 8Mbit and/or on
SPI 16Mbit
Video sub-system
Integrated, based on Intel
®
Graphics
Media Accellerator x3100, with high
performance 3D graphics.
Analogue video interface (CRT)
300 MHz frequency DAC with resolution
up to 2048 x 1536.
Analogue video output on connector
SUBD-H15.
Video digital interface (LCD)
output LVDS dual channel at 6/8 bits for
colour with resolution up to 2048x1536
Video digital interface DVI
output DVI on DVI-D single link
connector, with resolution up to
1920x1200
Video RAM
Up to 256MB shared
Floppy disk Controller
Integrated on motherboard
IDE Interface for mass memories
1 bus Fast IDE, Integrated on
motherboard
SATA Interface for mass memories
3 SATA 300Mbit/s, Integrated on
motherboard
Parallel Port
1 Integrated, configurable in modes
SPP, ECP, EPP (optional)
Serial Ports
2 x RS232
1 x RS232 / RS422 / RS485 automatic
(optional)
1 x TTL (Touchscreen)
Mouse Port
Type PS/2 integrated
Keyboard Port
Type PS/2 integrated
Touchscreen
Controller integrated on-board
USB
8 ports 2.0 (2 internal)
Local network
LAN1 10/10/1000 Mbps based on Intel
82574L
LAN2 Gigabit based on Intel 82566M
Compact Flash
Slot Compact Flash Type 2 with ATA
interface
mini PCI connector
Connector for support of
communications modules.
