ASEM CPU 1021/A - Reset Watch Dog (JP15); Selection of Type of Dimming Control and Backlight (JP2, JP3, JP16, JP17, JP18); Selection of Power Supply (JP21 - JP22)

CPU 1021/A User’s Guide
18 Asem S.p.A.
Reset Watch Dog (JP15)
JP15
Generated signal
Dis
Watch-dog disabled (default)
Ins
Watch-Dog generates Reset
See also Chapter 1 > Watch Dog.
Selection of type of dimming control and Backlight (JP2, JP3,
JP16, JP17, JP18)
JP2
JP3
JP16 - JP18
JP17
inverter
Ins
Ins
Dis
Ins
Toshiba VNR104C11S-INV
Ins
Ins
Dis
Ins
TDK CXA-0368, CAX-0509
Ins
Ins
Ins
Dis
Green & Tech GH027/GH027I
Ins
Ins
Ins
Dis
EVT DA1405-07
Ins
Ins
Ins
Ins
LED backlight LCD panels
Selection of power supply (JP21 - JP22)
JP21
JP22
Ins
Ins
