ASEM CPU 1021/A - J9 - Connector VGA; J10 - Connector DVI-D

Connectors
Asem S.p.A. 27
17
GND
18
GND
19
TXB2-
20
TXB2+
21
TXB3-
22
TXB3+
23
TXCLKB-
24
TXCLKB+
25
GND
26
VL
27
FPBACK
28
VW
29
FPVDD
30
FPVDD
J9 - Connector VGA
PIN
Signal
PIN
Signal
PIN
Signal
1
Red
6
GND (Red)
11
NC
2
Green
7
GND (Green)
12
SDA
3
Blue
8
GND (Blue)
13
H sync
4
N.C.
9
5V
14
V sync
5
GND (Sync)
10
GND (Sync)
15
SCL
J10 - Connector DVI-D
PIN
Signal
PIN
Signal
PIN
Signal
1
TX 2-
9
TX 1-
17
TX 0-
2
TX 2+
10
TX 1+
TX 0+
3
GND
11
GND
GND
4
NC
12
NC
NC
5
NC
NC
NC
6
DDC_CLK
14
VCC fuse
GND
7
DDC_DAT
15
GND
TXCLK-
8
VSINC
16
hpdet
TXCLK+
