ASEM CPU 1021/A - J11 - Connector Inverter LCD or Power LED LCD; J12 - Connector HD SATA1;2; J17 - Connector Compact Flash IDE (50 Pin) (Type I - II)

CPU 1021/A User’s Guide
28 Asem S.p.A.
J11 - Connector inverter LCD or power LED LCD
PIN
Signal
1 - 2
+ 12 V
3 - 4
GND
5
PWM
6
FPBACK
7
V
W
8
V
L
J12 - Connector HD SATA1/2
PIN
Signal
1
GND
2
TX+
3
TX-
4
GND
5
RX-
6
RX+
7
GND
J17 - Connector Compact Flash IDE (50 pin) (type I - II)
PIN
Signal
PIN
Signal
1
GND
26
N.C.
2
DATA (3)
27
DATA (11)
3
DATA (4)
28
DATA (12)
4
DATA (5)
29
DATA (13)
5
DATA (6)
30
DATA (14)
6
DATA (7)
31
DATA (15)
7
IDE CHIP SELECT 1
32
IDE CHIP SELECT 3
8
GND
33
N.C.
9
GND
34
I/O READ/
10
GND
35
I/O WRITE/
