ASEM CPU 1021/A - Bios Recovery (JP6); Display LCD Resolution (JP7, JP8, JP9); Enable Controller LAN1 (JP10); Enable Warning CPU Temperature (JP11)

Hardware setup
Asem S.p.A. 17
Bios recovery (JP6)
JP6
Function
Ins
BIOS recovery
Dis
default
Display LCD resolution (JP7, JP8, JP9)
LCD
JP9
JP7
JP8
JP1
640x480
Ins
Ins
Ins
2-3
800x600
Toshiba LTM08C351L,
Toshiba LTD12C32S
Toshiba LTD12C33S
*Mitsubishi AC121SA01
Ins
Dis
Ins
2-3
1024x768, 1Pixel/Clock
Samsung LTM150XH-Lxx
Sharp LQ150X1Lxxx
*CMO G121X1-L03
*NLT
Ins
Ins
Dis
2-3
1280x1024, 2Pixel/Clock
Samsung LTM170EU-Lxx
*AUO G170EG01.V1
Ins
Dis
Dis
1-2
1024x768, 1Pixel/Clock, 6 bit per
color
Toshiba LTA121C250F
*Sharp LQ190E1LW72
Dis
Dis
Ins
1-2
* LED backlight LCD panels.
Enable controller LAN1 (JP10)
JP10
LAN1
Ins
Disabled
Dis
Enabled
Enable warning CPU temperature (JP11)
JP11
Function
Ins
Enabled
Dis
Disabled
