Description
Asem S.p.A. 5
LCD display connection
The card CPU 1021/A allows, by means of connector J5, interface
with a wide display of colors with TFT technology and LVDS input
To connect an LCD display to the card CPU 1021/A, proceed as
follows:
• Set the three jumpers JP7, JP8, JP9 according to the table for
the types of LCD panels. Refer to the chapter Hardware setup.
• Connect the inverter to the connector J11.
• Set the jumpers JP1 (power supply), JP2 – JP3 – JP16 – JP17,
JP18 (type of inverter) referring to the chapter Hardware setup.
• Power on the system, enter SETUP and set the video output to
the desired mode.
In SETUP, adjust the brightness of the lamps of the LCD panel (the
range of values is 0-100 in steps of 10).
Floppy disk controller
The floppy disk controller integrated on the motherboard allows
management of 1 floppy disk drives with capacity of 360 KB, 720 KB,
1.2 MB, 1.44 MB, 2.88 MB.
IDE controller
The CPU 1021/A integrates a controller for a primary IDE channel
that can manage a master unit (default). Mass memories are
supported of the following types: Compact FLASH.
SATA controller
The CPU 1021/A integrates a controller for three SATA channels that
can support mass memories like hard disk and DVD.
On the motherboard there are 4 SATA connectors (J12 – J14 – J15
– J16), J14 and J15 refer to the same channel.
