ASEM CPU 1021/A - J1 - Connector Tachometric Fan 12 V for CPU; J2 - Connector Tachometric Fan 12 V for System; J3 - Connector for Two Tachometric Fans 12 V for CPU; J5 - Connector LVDS 6;8 Bit Color LCD

CPU 1021/A User’s Guide
26 Asem S.p.A.
J1 - Connector tachometric fan 12V for CPU
PIN
Signal
1
GND
2
+ 12 V (modulated from PWM)
3
SPEED
J2 - Connector tachometric fan 12V for system
PIN
Signal
1
GND
2
+ 12 V (modulated from PWM)
3
SPEED
J3 - Connector for two tachometric fans 12V for CPU
PIN
Signal
1
GND
2
+ 12 V (modulated from PWM)
3
SPEED FAN B
4
SPEED FAN A
J5 - Connector LVDS 6/8 bit color LCD
PIN
Signal
PIN
Signal
1
TXA0-
2
TXA0+
3
TXA1-
4
TXA1+
5
TXA2-
6
TXA2+
7
GND
8
GND
9
TCLKA-
10
TCLKA+
11
TXA3-
12
TXA3+
13
TXB0-
14
TXB0+
15
TXB1-
16
TXB1+
