ASEM CPU 1021/A - J33;J34;J35 - Connector for Power Supply for Mass Memory Units; J37 - Connector Power Supply ATX

CPU 1021/A User’s Guide
34 Asem S.p.A.
8
DATA (6)
21
GND
9
DATA (7)
22
GND
10
ACK/
23
GND
11
BUSY
24
GND
12
PAPER EMPTY
25
GND
13
SELECT
/
/
J33/J34/J35 - Connector for power supply for mass memory
units
PIN
Signal
1
12V
2 / 3
GND
4
5V
J37 - Connector power supply ATX
PIN
Signal
1
3.3V
2
3.3V
3
GND
4
VCC (5V)
5
GND
6
VCC (5V)
7
GND
8
N.C.
9
5VSB
10
+12V
11
3.3V
12
-12V
13
GND
14
PS ON
