CPU 1021/A User’s Guide
24 Asem S.p.A.
Connector
Description
J1
Connector tachometric fan 12V for CPU
J2
Connector tachometric fan 12V for system
J3
Connector for two tachometric fans 12V for CPU
J4
Connector ITP 700 (testing)
J5
Connector LVDS 6/8bit color LCD
J6
Connector SODIMM DDR2
J7
Connector SODIMM DDR2
J8
Connector for communication modules
J9
Connector video VGA
J10
Connector DVI-D
J11
Connector inverter LCD or power LED LCD
J12
Connector HD SATA1
J14
Connector HD SATA2
J15
Connector HD SATA2 (solder side)
J16
Connector HD SATA3
J17
Connector Flash Type II
J18
Connector USB ports 4-5 protected
J19
Connector USB ports 7 internal
J20
Connector USB ports 6 internal
J21
Slot riser card
J22
Connector RJ45 (LAN2) + USB ports 2-3
J23
Connector RJ45 (LAN1) + USB ports 0-1
J24
Connector floppy disk
J25
Connector floppy disk solder side
J26
Connector serial multistandard COM3 (internal)
J27
Connectors DB9 serial ports RS232 COM1 & COM2
J28
Connector front plate
J29
Connector mouse/Keyboard (encoder)
J30
Dual connector for keyboard (lower) / mouse (upper) PS/2
