Page 6 of 23
Standard Equipment
All DTT meters are supplied with the following standard items:
• DTT torque meter
• Rundown adapter (see chart below)
• Carrying case with insert
• Battery charger
• Mini USB to USB cable (ASG #66629)
Additional optional
rundown adapters can
be found on page 7
Included with DTT-5 (66700)
ASG Number Type Drive Size
Torque Range
Spring Color
lbf.in N.m
66620 Adapter w/ Spring 4mm HIOS 0.25 - 2.0 0.03 - 0.23 Black
CP66612 Adapter 1/4” Hex N/A N/A N/A
CP66614 Spring N/A 1.3 - 5.0 0.15 - 0.56 Yellow
Included with DTT-10 (66701) and DTT-30 (66702)
ASG Number Type Drive Size
Torque Range
Spring Color
lbf.in N.m
66620 Adapter w/ Spring 4mm HIOS 0.25 - 2.0 0.03 - 0.23 Black
CP66612 Adapter 1/4” Hex N/A N/A N/A
CP66614 Spring N/A 1.3 - 5.0 0.15 - 0.56 Yellow
CP66616 Spring N/A 4.5 - 26.0 0.51 - 2.9 Black
Included with DTT-50 (66703) and DTT-100 (66704)
ASG Number Type Drive Size
Torque Range
Spring Color
lbf.in N.m
66633 Adapter w/ Spring 4mm HIOS 4.5 - 26.0 0.51 - 2.9 Black
66617 Adapter w/ Spring 1/4” Hex 4.5 - 26.0 0.51 - 2.9 Black
66618 Adapter w/ Spring 1/4” Hex 25.0 - 80.0 2.8 - 9.03 Black
Included with DTT-200 (66705)
ASG Number Type Drive Size
Torque Range
Spring Color
lbf.in N.m
66618 Adapter w/ Spring 1/4” Hex 25.0 - 80.0 2.8 - 9.03 Black
66634 Adapter w/ Spring 3/8” Hex 50.0 - 200.0 5.6 - 22.6 Black
Included with DTT-500 (66706)
ASG Number Type Drive Size
Torque Range
Spring Color
lbf.in N.m
66618 Adapter w/ Spring 1/4” Hex 25.0 - 80.0 2.8 - 9.03 Black
66642 Adapter w/ Spring 3/8” Hex 50.0 - 500.0 5.6 - 56.5 Black
ASG #CP66614 and
#CP66616 are springs
to be used with
#CP66612 Adapter
