Electrical connection
2 phases - 1 neutral3 phases - 1 neutral
4x1.5 mm
2
Cross sectional area:
Cross sectional area:
5x1.5 mm
2
2 phases - 2 neutral (only for NL)1 phase - 1 neutral
5x1.5 mm
2
Cross sectional area:
Cross sectional area:
3x4 mm
2
NOTE!
Consult the wiring diagrams on the bottom of the appliance.
Total loadL3L2L1Connected load
7410 W10 W3700 W3700 W
41
