Asko TL751 - Page 20

19
G01
G07
G04
G06
G02
G09
G03
G08
G05
10. CABINET FRONT ASS'Y
G01 CABINET FRONT AS 3610812510 WHITE 1 TL751/G/CA XXLW
3610812550 PLATINUM 1 TL751/G/CA XXLPP
3610812560 RED ROSE 1 TL751/G/CA XXLRR
G02 GASKET CABINET F 3612323350 EPDM 5x10 3.0T R207 4
G03 SUPPORT HINGE 3615304410 SGCC 1.6t 1 LEFT DOOR TYPE
3615304415 1 RIGHT DOOR TYPE
G04 DOOR LOCK AS 3613802500 1
- SCREW MACHINE 7002401608 T2S TRS 4x16 SUS430 2 For fixing door lock as
G05 SWITCH DOOR 3619047700 125V 7.5A 1
G06 DOOR AS - 1 Refer to 17 page
- SCREW TAPPING 3616030000 F/L BOLT(SE) 5x12 SUS 4 For fixing hinge & cabinet f
G07 LABEL WARNING F 3613558800 PVC 1
G08 LABEL CAUTION F 3613557600 PVC 1
G09 LABEL RATING 3613558900 PVC 1
No. Part Name Part Code Description Qtt'y Remark
