Electric Parts List - Gas Clothes Dryer
Part Name Part Code Type No Rating Main function
Lamp AS 3612625300
Lamp Holder: 4000 series 75W, 125V
Power is applied to the lamp to turn up the
Lamp Base: E12 15W, 125V
light in the drum when the door is opened.
Switch Door 3619047700 SPE110F-1D3 7.5A 125V / 5A 250V AC
Thermistor Fan 361AAAAC20 CWT-DEW-1C18-A 5V R40=26.065
KΩ
Themistor fan senses the temperature of
R90=4.4278
KΩ
exhaust air and turns on/off the heater if
the temperature is higher/lower than the
set temp.
Switch Micro 3619047500 GSM-V1622A2 125V/250V 16A N-C Switch micro detects a loosened or broken
belt so as to block power to the motor.
Motor Dryer 36189L5D00 S58NXSDD-6989 120V 60Hz 5.9A CL.B The motor rotates the drum to dry laundry
evenly and the fan to expel wet air.
Igniter AS 36189L5800 DC033 120V 60Hz 4.0A When power is supplied, igniter is heated
to 980°C (1800 °F) within 30 seconds to
ignite gas.
Flame Sensor 3614825700 10RS 43828 120V 60Hz 5.75A When heat source is detected, contact
point is opened within 12 ~ 20 seconds to
turn off igniter before gas ignition. When
heat source is extinguished, contact point
is closed within 26 ~ 40 seconds.
Thermostat 3619047610 60T21 95°C Off, 70°C On To prevent overheating around burner
Hi-Limit 125V/25A 250V/25A during normal operation, power line of
flame sensor is cut off when the
temperature detected reaches 95°C and
is restored when the temperature falls
below 70°C.
Thermostat 3619047810 PBR-380 N110 110°C Off, -35°C On Overheating around burner is prevented
Cut-Out 125V/15A 250V/7.5A under abnormal conditions, such as
of lint filter or exhaust pipe blocking
(manual restoration possible by pressing
knob after operation commences).
Valve Gas AS 3615417200 "DEGB-1011, LPG"
2.0~3.5 kPa, 120V 0.07A
LPG gas is supplied or blocked off.
Valve Gas AS 3615417300 "DEGB-1011, LNG"
1.0~3.5 kPa, 120V 0.07A
LNG gas is supplied or blocked off.
* Parts surrounded by dotted line are exclusively for gas dryer. Other parts are common parts for electric/ gas dryer.
