Electric Parts List - Electric Clothes Dryer
Part Name
Lamp AS
Switch Door
Thermistor
Fan
Switch Micro
Heater
Motor Dryer
Thermostat
Fan
Thermostat
Hi-Limit
Thermostat
cut-out
Part Code
3612625300
3619047700
361AAAAC20
3619047500
3612802500
36189L5D00
3619047900
3619047600
3619047800
Type No
Lamp Holder: 4000 series
Lamp Base: E12
SPE110F-1D3
CWT-DEW-1C18-A
GSM-V1622A2
TGE-24050H
S58NXSDD-6989
PW3N
60T11
PW3V
Rating
75W, 125V
15W, 125V
7.5A 125V / 5A 250V AC
5V R40=26.065KΩ
R90=4.4278KΩ
125V/250V 16A N-C
120V/2500W,
240V/5000W, Ni/Cr
120V 60Hz 5.9A CL.B
85off 75on 125V/15A
250V/7.5A
125 Off 94 On 125V/25A
250V/25A
140Off -30On 125V/25A
250V/25A
Major Functions
Power is applied to the lamp to turn up
the light in the drum when the door is
opened.
Thermistor fan senses the temperature of
exhaust air and turns on/off the heater if
the temperature is higher/lower than the
set temp.
Switch micro detects a loosened or
broken belt so as to block power to the
motor.
2 2500-W heaters, consisting of Ni/Cr
coils, are connected in a parallel circuit.
The motor rotates the drum to dry laundry
evenly and the fan to expel wet air.
The fan detects excessively hot
temperatures and turns off the motor as
well as the heater in order to prevent
clothes from discoloration.
The control turns off the heater if the
temperature achieves 125 to prevent
overheating and on again if 94.
This part is a non-resettable safety device
that prevents overheating in case of
unusual conditions such as a clogged lint
filter or outlet duct.
