80
GAS BURNER ASS'Y
1. Remove 6 screws. And separate 2 valve connectors.
2. Remove 1 screws at the back of cabinet. 3. Remove 2 screws and separate igniter connecter.
3. Remove 2 screws after removing harness at thermostat Cut-Out, Hi-Limit.
