Asko TL751 - Support Drum Front Assy; Drum Assy; Pipe Exhaust

70
SUPPORT DRUM FRONT ASS'Y
1. Push up idler in the direction of arrow to remove belt. Then, separate belt and remove drum.
DRUM ASS'Y
1. Remove 1 rear screw and separate pipe exhaust in the direction of arrow.
PIPE EXHAUST
1. Remove 1 rear screw and separate pipe exhaust in the direction of arrow.
