Asko TL751 - Frame Upper and Connector Separation

68
FRAME UPPER
SEPARATION OF LAMP,PCB MAIN CONNECTOR
1. Separate lamp connector. 2. Separate main PCB connector.
3. Separate humidity sensor connector.
1. Remove 2 screws from left and right in front
part.
2. Remove 2 screws from left and right at the
top.
3. Separate frame upper after removing harness at the back.
