Asko TL751 - Dismantling Procedures for Dryer Assemblies; Panel, Plate Top, and Cabinet Front Dismantling

66
❑
DISMANTLING METHOD PER DRYER ASS'Y
PANEL FRONT ASS’Y
PLATE TOP ASS'Y
1.Remove left cap and unfasten screw.
2. Separate panel front. (CAUTION : Internal hook damage attention)
3. Separate plate top by pushing it at the front part in the direction of arrow.
1. Remove 3 screws at the front.
2. Remove 4 screws at the back.
