Service manual WM70
41
Technical data WM70
Height: 850 mm
Width: 595 mm
Depth: 585 mm
Weight: 77 kg / 81 kg (with outer door)
Cylinder volume: 60 l
Max. washing capacity EU 7,0/8,0kg, AU 7,0kg US 7,0/8,0kg Swan 6,0 kg
Spin speed: WM70.3 400–1800 rpm, WM70.2 400–1800 rpm, WM70.1 400 –1600 spm
Connection: 1 phase 10 A
Element power: 2000W, 230V (See Type designation)
Water pressure/inlet valve: 0,1 – 1 MPa., 1 – 10 kp/cm2, 10 –  .CM2. 8 litre/min
Wash drum and liquid compartment
material:
Stainless steel
Outer casing material: Powder coated and galvanized sheet steel or stainless steel
Set-up: Stationary on four adjustable, rubber-covered feet
Water connection:  M PEX PIPE v n v ELLER v n v
Drain: 1,7 m polypropylene tube
Protection class: IP X4
Water consumption (tested normal program) 65 litre (3-rinse), <78 litre (5-rinse)
Energy consumption (tested normal
program)
8kg: 1,2kWh, 6kg: 1,14kWh
Electricity consumption, Standby:
- Main power switch off
- Display on
- Display off
<0,3 W
<6,0 W
<3,0 W
Tools
Torx; T25, T20, T10
Socket screwdriver 10 mm
5mm socket head cap screwdriver + small locking handle
2ING SPANNERS     MM  MM  MM
24mm extended socket + locking handle
Plastic hammer
Star socket head screwdriver
A pair of nippers
