Service manual WM70
46
Rehanging the door
Instructions Image
1. Remove the plinth by carefully pulling it
out.
2. Remove both screws for the lower hinge.
Use Torx.
3. Push the door upwards with care and
angle outwards. If necessary, carefully press
the lower hinge to detach the door.
4. Slacken off the lower and upper hinge
pins using a fixed spanner.
Some machines in the WM60-series is supplied with a door - is that the case the door is hung on
the left-hand side. It is, however, possible to re-hang it according to the instructions below. Take
care not to damage the paint when carrying out work with tools.
Required tools
Flathead screwdriver
Torx size 20
Fixed spanner size 8
