Functions
ED3000 Series Parts Manual
Device with Trim
Device Type ANSI # Description
Trim
Designation*
ED3210, ED3410,
ED3610
Passage 14 Free at all times XX3310
ED3210A, ED3410A,
ED3610A
Passage 14 3-hour fire-rated, Free at all times XX3310
ED3210AT,
ED3410AT,
ED3610AT
Thumbpiece Passage 15 3-hour fire-rated, Free at all times T3X10
ED3210T, ED3410T,
ED3610T
Thumbpiece Passage 15 Free at all times T3X10
ED3250, ED3450,
ED3650
Dummy/Exit Only 01/02 Always rigid; Exit only XX3350, T3X50
ED3250A, ED3450A,
ED3650A
Dummy/Exit Only 01/02 3-hour fire-rated, Always rigid; Exit only XX3350, T3X50
ED3255, ED3455,
ED3655
Classroom 08 Free at all times except when locked by key XX3355
ED3255A, ED3455A,
ED3655A
Classroom 08
3-hour fire-rated, free at all times except
when locked by key
XX3355
ED3255AT,
ED3455AT,
ED3655AT
Thumbpiece
Classroom
05
3-hour fire-rated, free at all times except
when locked by key
T3X55, T3XM55
ED3255T, ED3455T,
ED3655T
Thumbpiece
Classroom
05 Free at all times except when locked by key T3XX55, T3XXM55
ED3257, ED3257A Nightlatch 03
Entrance by trim when latchbolt is
retracted by key. Key removable only when
locked
XX3357, T3X57
ED3457, ED3457A Nightlatch 09
Entrance by trim when latchbolt is
retracted by key. Key removable only when
locked
XX33V57
ED3657, ED3657A Nightlatch 03
Entrance by trim when latchbolt is retracted
by key. Key removable only when locked
XX33M57,
T3XM57
* When ordering a device, the function must be included in the device component of the order string and must match the trim function
(e.g. ED3255/A3355). See pages 11-12.
