Assa Abloy Corbin Russwin Access 3 - ED5470(B) X M55 (Less Bottom Rod) Surface Vertical Rod

14
ED5470(B) x M55 (Less Bottom Rod)
Surface Vertical Rod
ED4000, ED5000 Parts Manual
Item No. Part No. Description Qty. Sellable
1
650F388 Active Head, ED5470(B) RHR
1
Yes
650F398 Active Head, ED5470(B) LHR Yes
2
650F01 x Fin Cover, ED5470
1
Yes
--- Cover, ED5470B No
3 652F298 Sex Nut Pack, Fire Only & M54 4 Yes
4 684F42 x Fin Rod Extension Assembly, 24" 1 Yes
5 655F17 x Fin Rod Extension Assembly, 12" 2 Yes
N/A
655F15 x Fin 2" Rod Extension* 1 Yes
655F16 x Fin 6" Rod Extension* 1 Yes
23 704F63 x Fin Cover Screw Packet, #8-32 x 5/16" 1 Yes
32 650F64 x Fin Top & Bottom Latches Cover 2 Yes
33
650F558 Top Latch, ED5470
1
Yes
650F568 Top Latch, ED5470B No
34
654F158 SVR Pack 1 Yes
681F708 Top Strike Packet 1 Yes
36 650F60 x Fin Top Rod 1 Yes
39 650F62 x Fin Rod Guide Packet 1 Yes
40 675F99 x Fin Rod Guide Cover 2 No
55 744F688 x Fin Popper Packet [Fire Rated (B) Only] 1 Yes
N/A 654F208 Wood Screw Packet* 1 Yes
* Not Shown
