TH910, TH950, TH955, TH957,
TH959 Trim
ED4000, ED5000 Parts Manual
Item Part # Description Sellable
1
566F522 x Fin Escutcheon - TH950 Yes
566F532 x Fin Escutcheon - TH910 Yes
566F542 x Fin Escutcheon - TH957 Yes
566F552 x Fin Escutcheon - TH955, TH959 Yes
2 566F50M x Fin Thumbpiece - TH910, TH955, TH959 No
3 566F572 x Fin Grip Yes
4 677F118 Screw, Set 1/4-20 x 5/8 - TH910, TH955, TH959 Yes
5 566F588 Spacer, Grip - TH910, TH955, TH959 Yes
6 651F468 Thumbpiece Support Bracket - TH910, TH955, TH959 Yes
8 651F448 Lock Washer Yes
9
651F418 Screw, RHM-PH #1/4-20 x 5/8” - TH950, TH957 Yes
704F898 Screw, PHM-PH #1/4-20 x 1” - TH910, TH955, TH959 Yes
10 651F498 Thumbpiece Slider - TH910, TH955, TH959 Yes
11 651F488 Thumbpiece Pin - TH910, TH955, TH959 Yes
13 651F478 Thumbpiece Spring - TH910, TH955, TH959 Yes
14 651F545 Clutch Housing SA - TH910, TH955, TH959 Yes
15 651F398 Spring, Bushing, Comp - TH910, TH955, TH959 Yes
16 651F408 Compression Spring - TH910, TH955, TH959 Yes
17
566F598 Spindle SA - TH910, TH955, TH959 Yes
655F698 Spindle SA - TH910, TH955, TH959 Yes
18 651F508 Screw, PHT-T-PH #6 x 3/8” - TH910, TH955, TH959 Yes
19 651F438 Threaded Post Yes
20 386F018 Retaining Ring Yes
21
655K03MSECFIN Rim Cylinder Assembly - TH955, TH959 (Non X Class) Yes
655K04MSECFIN Rim Cylinder Assembly - TH955, TH959 (X Class) Yes
684K40MSECFIN Rim Cylinder Assembly - TH957 (Non X Class) Yes
684K43MSECFIN Rim Cylinder Assembly - TH957 (X Class) Yes
22
651F675 Cylinder Housing SA - TH955, TH959 Yes
651F425 Nightlatch Cylinder Housing - TH957 Yes
23
652F148 x Fin Screw Packet - 1-3/4” - 2” doors Yes
652F158 x Fin Screw Packet - 2-1/4” doors Yes
24 651F10M x Fin Bottom Escutcheon SA No
