9
Visual Key Control
Technical Manual
For Multiplex Masterkey Systems (CR keyway family shown)
Nickel silver
Key Bow type 38
• Ordering example AP Key Blank:
XXXX-6PIN-38-AP
• Ordering example AS/AHS Key Blank:
XXXX-6PIN-38-AS60
• Ordering example Hotel Emergency key (Mortise Cylinders)
example: Keyway-6Pin-38-E2-AP
• Ordering example Hotel Emergency key (Key-in-lever cylinders)
example: Keyway-6Pin-38-E6-AS60
Back Side Stamping & Options
• Key set (VKC1), standard – unless otherwise indicated
• System registry number will be stamped on master keys unless otherwise indicated
• Concealed key control (CKC2) available on cylinders
• Visual Key Control VKC2 is available for level 1 (AP) only.
• Visual Key Control VKC3 and Concealed Key Control CKC3 not available
Key Section Code
(blind code
for keyway
designation)
Key Set Symbol
System
Registry
Number
Front Side Back Side
Keyway
Keyway
