ML2000 Series Mortise Lock
Installation Instructions
Used with VN Escutcheon Trim and V Series Indicators
FM521 08/19
Copyright © 2019, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
For installation assistance contact Corbin Russwin
1-800-543-3658 • techsupport.corbinrusswin@assaabloy.com
1 Tools Required
• Phillips screwdriver (#1, #2 and #3 sizes)
• Flat-blade screwdriver
• 1/8" Allen wrench - standard trim
• 3/32” - Muséo®
• 7/64” - ML20900/ML20600 - NAC
• 3/8" dia. drill bit
2 Indicator Variants
Depending on function and option ordered,
indicators are provided in the following variations.
These instructions detail how to install with
cylinder, however other variations follow similar
instructions. (Figure1)
Contact factory with any questions.
Cylinder – For installation on
inside or outside of door.
Coin Turn – For installation on
outside of door.
Thumbturn - For installation
on inside of door.
No input/blank - For
installation on inside of door.
Figure1
