05/15/15
Copyright © 2015, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
Harmony Series H1 Mortise Lock
A7877F • 800-810-WIRE (9473) • www.sargentlock.com
5
ITEM PART # Description Req.
1 52-5188 Outside Harmony Escutcheon With Cylinder Prep 1
1A 52-5189 Outside Harmony Escutcheon Without Cylinder Prep 1
2 52-0796 Outside Weather Gasket 1
3 52-0795 Inside Weather Gasket 1
5 52-5236 Screw Pack (5A; 5B; 5C; 5D) 1
5A 77-1467 8 x 32 x 2" Phillips Head Flat Head Machine Screw 2
5B 01-9242 8 x 32 x 5/8" Phillips Head Flat Head Undercut Machine Screw 2
5C 01-1028 8 x 32 x 1/4"Phillips Head Flat Head Undercut Machine Screw 1
5D 01-1176 8 x 32 x 3/8" Phillips Head Flat Head Undercut Tapping Screw 4
6 52-5184 Inside Escutcheon w/ Turn Assembly 1
6A 52-5185 Inside Escutcheon w/out Turn Prep 1
7 -- Reference Harmony Series Catalog For Available Lever Styles 1
8 -- Reference Harmony Series Catalog For Available Rose Styles 1
9 82-0368 Inside Spindle 1
10 01-1495 8-32 x 5/8" Screws 2
11 82-3088 Inside Adapter Plate And Bushing Assembly 1
11A 82-4577 Inside Adapter Plate And Bushing Assembly (Dl) 1
12 -- Reference Harmony Series Catalog For Available Lever Styles 1
13 -- Reference Harmony Series Catalog For Available Cylinders (Size 43) 1
14*
Lock Body
†
H1-82270-12/24 VDC x Finish w/out Deadbolt, Fail Safe** 1
H1-82271-12/24 VDC x Finish w/out Deadbolt, Fail Secure** 1
H1-82272-12/24 VDC x Finish w/out Deadbolt, Fail Safe, Both Levers Lock** 1
H1-82273-12/24 VDC x Finish w/out Deadbolt, Fail Secure, Both Levers Lock** 1
H1-82280-12/24 VDC x Finish w/ Deadbolt, Fail Safe** 1
H1-82281-12/24 VDC x Finish w/ Deadbolt, Fail Secure** 1
H1-82282-12/24 VDC x Finish w/ Deadbolt, Fail Safe, Both Levers Lock** 1
H1-82283-12/24 VDC x Finish w/ Deadbolt, Fail Secure, Both Levers Lock** 1
15 82-0579 Outside Faceplate w/ Deadbolt 1
15A 82-0578 Outside Faceplate w/out Deadbolt 1
16 82-0110 Strike Plate 1
17 01-2299 #12 X 1 1/4" Phillips Flat Head Wood Screw 2
18 01-1019 12-24 X 1/2" Phillips Flat Head Undercut Machine Screw 4
19 01-1028 8-32 X 1/4" Phillips Flat Head Undercut Machine Screw 2
20 01-2298 #12 X 1" Phillips Flat Head Wood Screw 2
21 A7944 Field Prep Template (not shown) 1
22 4590 Door Manufacturer Template (not shown) 1
23 A7877 Installation Instructions (not shown) 1
Lever Hand Reverse Door
Parts Breakdown (Continued)
*Patent Pending
†
For EOL (End-of-Line Resistor) and PHR locks, please consult factory
**CAUTION: Not recommended for use on any door used for Life Safety Egress
