49
ASSA ABLOY Hospitality
66 8003 015-3
Appendix A: Quick reference of technical data
Note: If external motion sensor is applicable, see Installation manual Orion High Voltage
Thermostat for technical data and information about installation.
Dimensions (WxHxD)
112 x 117 x 35 mm (4 13/32" x 4 19/32" x 1 3/8")
Mains voltage input
Universal voltage input 100VAC-277VAC; 50/60Hz;
rated impulse voltage: 4kV
Switch input
Door switch - 1 exterior/1 interior
Multifunction input
Motion sensor/card switch/pipe temp sensor
High voltage outputs
- G1 (Fan 1): Type 1.B action. Max load 3A (3FLA/18LRA)
- G2 (Fan 2): Type 1.B action. Max load 3A (3FLA/18LRA)
- G3 (Fan 3): Type 1.B action. Max load 3A (3FLA/18LRA)
- RV (reversing valve): Type 1 action. Max load 0.5A
- Y (cooling/compressor): Type 1 action. Max load 0.5A
- W (heating): Type 1 action. Max load 0.5A
Low voltage outputs
- Proportional 0-10V; heating
- Proportional 0-10V; cooling
- Switch output (max 24V AC/DC, SELV, max 0.1A)
Temperature sensor
Integrated in thermostat
Temperature display
Configurable: room temperature (default) or
guest setting
Temperature display range
2-digit display
Adjustable setpoint
temperature range
17°C - 32°C / 62F - 90F
Environment
Normal indoor environment - Pollution degree 2
Operating temperature range 0°C - 55°C / 32F -130F
Temperature sensor
Integrated in thermostat
Service device
Orion Service software and
service cable RJ12 to 3.5mm stereo jack
Radio (RF) signals
ZigBee 2006
Lock to thermostat:
Door open - staff card
Door open - guest card
Door open from inside
Door closed
Deadbolt thrown/released
Thermostat to lock:
Room occupied
Motion sensor to thermostat:
Motion detected
Battery status
Thermostat to motion sensor:
Turn off when the room is occupied and door is closed
Turn on when the door is opened again
