Intended use
The ASSA ABLOY SW60 is an automatic swing door operator developed to make life easier for everyone
who can benefit from automatic doors. The A SSA ABLOY SW60 is a low-energy operator using a DC
motor and a gear-reduction system to drive an arm system, which opens the door. It is to be installed
on the interior swing doors. This widely-used operator can be found in applications in health care,
office and public buildings.
The door is designed to offer continuous use, a high degree of safety and maximum lifetime. The
system is self-adjusting to the effects caused by normal variations in the weather conditions and to
minor friction changes caused by e.g. dust and dirt.
For escape in emergency situations the doorset is opened manually.
Make sure that the connection to the source of supply by a flexible cord shall not be allowed to be-
come entrapped in moving parts of the operator or door system.
The glazing material in unframed swinging doors and/or framed swinging doors except that
glazing material is less than 1 ft
2
(0.9 m
2
) and having no dimension greater than 18" (457 mm)
shall be comply with the requirements of ANSI Z97.1.
Please use the adaptor provided with the operator in the packaging, other adaptor may result in risk
of fire.
For installation and maintenance see Installation and Service manual 1020004.
Technical specification
ASSA ABLOY Entrance SystemsManufacturer:
1900 Airport Road, Monroe, NC 28110, USAddress:
ASSA ABLOY SW60Type:
120 V AC +10/-15%, 50/60 HzMains power supply:
Max. 90 WPower consumption:
IP20Degree of protection:
The ASSA ABLOY SW60 complies with ANSI/BHMA A156.19.Standards:
How the ASSA ABLOY SW60 works
The swing door operator ASSA ABLOY SW60 uses a DC motor and a gear-reduction system to drive
an arm system which opens the door. Closing power is provided by a motor and a closing spring. A
highly sophisticated electronic control unit uses a motor encoder and a microprocessor to control
the door’s movement.
To activate the operator you can use wall or jamb-mounted contact switches or activate through
the app. It is also possible – where local standards allow – to activate the operator by just pushing
the door, if "Push and go" is active.
After the door has been activated it will open and stay in the open position for a specified "Hold
open time". When "Hold open time" has elapsed the door will close.
App
1019650-en-US-5.0Issue 2021-02-036
