6000 Series Grade 1 Exit Devices
12
6220 Concealed Vertical Rod
Copyright © 2015-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and
Egress Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Item Part No. Description
1
Latch Case Assembly
60-6220-0354-048 (Must Specify Hand)
2 60-6000-X003-FIN Cover, Latch Assembly
35 60-7220-0065-048 Bottom Bolt Case
36 60-7220-1019-059 Top Rod
46
81-9500-1456-000 CVR Pack
Consists of the following:
60-7010-1070-018 Floor Bolt
60-7010-1055-200 Strike
81-9500-1454-200 791 Top Strike Packet
60-7120-1047-048 Pin, Rod Yoke (2)
60-7140-1026-059 Set Screw, Yoke Pin (2)
60-7020-1064-059 Yoke Pin Shim (2)
99-9958-0045-999 Cotter Pin (5)
99-9999-4526-999 Ring, Retaining (2)
81-0014-0430-036 2” Temp Screw (2)
81-9500-1548-058 Screw Pack
47 60-7220-0066-048 Top Latch & Bracket Assembly
49 60-7020-0059-000 Bottom Rod & Coupler Assembly
51 60-7220-7025-000 Top Rod Tube
52 60-7220-0030-999 Arm & Bracket Assy (2)
To Next Page
